Specifications
| Parameter | Value |
|---|---|
| Model | JY168‑340 |
| Type | Self‑centering vise, combo jaw (soft jaw + hard jaw) |
| Dimensions (L × W × H) | 450 × 168 × 91 mm |
| Clamping range | 0–340 mm |
| Repeat clamping accuracy | 0.015mm |
| Max. torque | 150Nm |
| Jaw type | Combo jaws (soft jaw + hard jaw) |
Key Features
-
JIYAN precision engineering – designed and manufactured to exacting standards
-
Self‑centering design – automatically centers the workpiece for consistent positioning
-
Extended clamping range – 0–340 mm capacity handles very large workpieces
-
Combo jaw design – combines soft jaw flexibility with hard jaw rigidity in one vise
-
High precision – 0.015mm repeatability for reliable production accuracy
-
High torque capacity – 150Nm clamping torque for secure workholding
-
Versatile workholding – soft jaw side for delicate parts, hard jaw side for heavy‑duty clamping
-
Heavy‑duty construction – 450×168×91 mm robust design for maximum rigidity
Application Scenarios
-
Large CNC milling and machining centers – handles oversized workpieces with stability
-
Mixed production runs – one vise handles both soft jaw and hard jaw applications
-
High‑mix / low‑volume production – quick changeover between different part types
-
4th/5th axis machining – heavy‑duty design for rotary table applications
-
Delicate and finished surface clamping – soft jaw side protects workpiece surfaces
-
Large part clamping – 340 mm capacity accommodates oversized workpieces
-
Precision machining – 0.015mm repeatability for consistent part quality
Why Choose JIYAN
-
Self‑centering advantage – eliminates manual centering, reduces setup time
-
Extended clamping range – 340 mm capacity for very large parts
-
Combo jaw versatility – soft jaw + hard jaw in one unit for maximum flexibility
-
Soft jaw option – machine soft jaws to exact part geometry for optimal grip
-
High precision – 0.015mm repeatability ensures consistent part quality
-
Heavy‑duty construction – robust design for large workpiece clamping
-
Precision ground surfaces – verified for flatness and parallelism
-
Hardened steel body – durable construction for high‑cycle production
-
JIYANVISE reliability – trusted by CNC professionals worldwide
