A heavy‑duty JIYAN self‑centering vise (450×168×74 mm) with split soft jaw design, 0–340 mm clamping range, 0.015mm repeatability, and 150Nm torque. Ideal for large CNC machining, custom workpiece clamping, and oversized part workholding from JIYANVISE.
We typically respond within 24 hours.
| Parameter | Value |
|---|---|
| Model | JY168‑340R |
| Type | Self‑centering vise, soft jaw |
| Dimensions (L × W × H) | 450 × 168 × 74 mm |
| Clamping range | 0–340 mm |
| Repeat clamping accuracy | 0.015mm |
| Max. torque | 150Nm |
| Jaw type | Split type hardened steel jaws (soft jaw滑块) |
JIYAN precision engineering – designed and manufactured to exacting standards
Self‑centering design – automatically centers the workpiece for consistent positioning
Extended clamping range – 0–340 mm capacity handles very large workpieces
Soft jaw design – split type soft jaws allow custom machining for specific part geometries
Low profile – 74 mm height saves Z‑axis clearance on CNC machines
High repeatability – 0.015mm for reliable production accuracy
High torque capacity – 150Nm clamping torque for secure workholding
Heavy‑duty construction – 450×168 mm footprint for maximum rigidity
Machinable jaws – soft jaws can be milled to match custom workpiece profiles
Large CNC milling and machining centers – handles oversized workpieces with stability
Custom workpiece clamping – soft jaws can be machined to fit complex or delicate parts
High‑mix / low‑volume production – quick jaw changes for different part sizes
4th/5th axis machining – heavy‑duty design for rotary table applications
Delicate or finished surface clamping – soft jaws protect workpiece surfaces from damage
Large part clamping – 340 mm capacity accommodates oversized workpieces
Low clearance applications – 74 mm profile fits machines with limited Z‑axis travel
Self‑centering advantage – eliminates manual centering, reduces setup time
Extended clamping range – 340 mm capacity for very large parts
Soft jaw flexibility – machine jaws to exact part geometry for optimal grip
Low profile design – saves valuable Z‑axis clearance on CNC machines
Heavy‑duty construction – robust design for large workpiece clamping
Split jaw design – easy replacement and customization
Precision ground surfaces – verified for flatness and parallelism
Hardened steel body – durable construction for high‑cycle production
JIYANVISE reliability – trusted by CNC professionals worldwide
