A JIYAN self‑centering vise with high jaw design (170×90×62 mm), 0–114 mm external / 30–147 mm internal clamping range, 0.015mm repeatability, and dual pull stud compatibility (52 / H18). Ideal for CNC milling, zero point pallet systems, and large workpiece clamping from JIYANVISE.
We typically respond within 24 hours.
| Parameter | Value |
|---|---|
| Model | JY90‑150 |
| Type | Self‑centering vise, high jaw |
| Dimensions (L × W × H) | 170 × 90 × 62 mm |
| Clamping range (external / internal) | 0–114 mm / 30–147 mm |
| Repeat clamping accuracy | 0.015mm |
| Max. torque | 70Nm |
| Weight | 4.1KG |
| Jaw type | Split type hardened steel jaws |
| Mounting options | 52 pull stud hole + H18 pull stud hole (dual compatibility) |
| Additional mounting | Ø8.5 through holes × 2, Ø13.5 through holes × 8 |
JIYAN precision engineering – designed and manufactured to exacting standards
Self‑centering design – automatically centers the workpiece for consistent positioning
Dual clamping modes – supports both external clamping (0–114 mm) and internal clamping (30–147 mm)
High jaw design – 62 mm overall height provides deeper workpiece engagement
Extended clamping range – 147 mm internal capacity handles large workpieces
High repeatability – 0.015mm for reliable production accuracy
Split hardened jaws – durable, wear‑resistant, and replaceable
Dual pull stud compatibility – accepts both 52 pull studs and H18 pull studs for zero point mounting
High torque capacity – 70Nm clamping torque for secure workholding
Versatile mounting – multiple through holes for flexible fixture attachment
CNC milling and drilling – ideal for large prismatic parts requiring centered clamping
Automated pallet systems – dual pull stud options (52 / H18) enable quick change on zero point systems
Round and square workpiece clamping – external and internal modes handle diverse part shapes
High‑mix / low‑volume production – quick jaw changes for different part sizes
4th/5th axis machining – compact width fits tight rotary table envelopes
Tall workpiece clamping – high jaw design (62 mm) provides better grip on taller parts
Large part clamping – 147 mm internal capacity accommodates oversized workpieces
Precision machining – 0.015mm repeatability for consistent part quality
Self‑centering advantage – eliminates manual centering, reduces setup time
Dual clamping flexibility – one vise handles both external and internal workpieces
High jaw design – deeper jaw engagement for taller or irregular workpieces
Zero point ready – 52 and H18 pull stud holes allow direct mounting on zero point pallets
Split jaw design – easy replacement and customization for different part geometries
Extended clamping range – 147 mm internal capacity for large parts
Multiple mounting options – various through holes for flexible fixture attachment
Precision ground surfaces – verified for flatness and parallelism
Hardened steel body – durable construction for high‑cycle production
JIYANVISE reliability – trusted by CNC professionals worldwide
