An ultra‑compact JIYAN self‑centering vise (75×54×44 mm) with 0–33 mm external / 28–53 mm internal clamping range, 0.015mm repeatability, and direct EROWA / 3R pallet system compatibility. Ideal for small CNC machining, EDM, and precision workholding from JIYANVISE.
We typically respond within 24 hours.
| Parameter | Value |
|---|---|
| Model | JY54‑50A |
| Type | Self‑centering vise, low jaw |
| Dimensions (L × W × H) | 75 × 54 × 44 mm |
| Clamping range (external / internal) | 0–33 mm / 28–53 mm |
| Repeat clamping accuracy | 0.015mm |
| Max. torque | 40Nm |
| Weight | 1.0 KG |
| Jaw type | Integral type hardened steel jaws (low jaw) |
| Mounting options | Direct EROWA and 3R pallet system compatibility |
JIYAN precision engineering – designed and manufactured to exacting standards
Self‑centering design – automatically centers the workpiece for consistent positioning
Dual clamping modes – supports both external clamping (0–33 mm) and internal clamping (28–53 mm)
Low profile design – only 44 mm height, preserves Z‑axis clearance for tall workpieces
High repeatability – 0.015mm for reliable production accuracy
Integral hardened jaws – one‑piece jaw construction for maximum rigidity and durability
EROWA & 3R ready – direct mounting on EROWA and 3R pallet systems without adapters
High torque capacity – 40Nm clamping torque for secure workholding
Ultra‑compact and lightweight – 75×54 mm footprint and 1.0 kg weight save machine space
Small CNC milling and drilling – ideal for small precision parts requiring centered clamping
EROWA / 3R pallet systems – direct compatibility for quick change on standard pallet systems
EDM and precision grinding – compact size fits small machine envelopes
High‑mix / low‑volume production – quick changeover between different part sizes
4th/5th axis machining – ultra‑compact size fits tight rotary table envelopes
Small part clamping – 53 mm internal capacity for miniature workpieces
Low clearance applications – 44 mm profile fits machines with limited Z‑axis travel
Precision machining – 0.015mm repeatability for consistent part quality
Self‑centering advantage – eliminates manual centering, reduces setup time
Dual clamping flexibility – one vise handles both external and internal workpieces
Low profile design – saves valuable Z‑axis clearance on CNC machines
EROWA & 3R ready – direct mounting on standard pallet systems, no adapters needed
Integral jaw construction – one‑piece hardened jaws provide maximum rigidity
Ultra‑compact footprint – saves valuable machine table space
Precision ground surfaces – verified for flatness and parallelism
Hardened steel body – durable construction for high‑cycle production
JIYANVISE reliability – trusted by CNC professionals worldwide
